TDA2030 TDA2030A TDA 2030A new amplifier power amplifier TO-220

TDA2030 TDA2030A 14W hi-fi audio power amplifier TO-220

Features

■ Wide - range supply voltage , up to 36 V ■ Single or split power supply

▪️Short - circuit protection to ground Thermal shutdown

Description

The TDA2030 is a monolithic integrated circuit in the Pentawatt package , intended for use as a low frequency class - AB amplifier . Typically it provides 14 W output power ( d = 0.5 % ) at 14 V / 4 2. At 14 V or 28 V , the guaranteed output wer is 12 W on a 4 2 load and 8 W on an 8 9 ( DIN45500 ) . The TDA2030 provides high output current and has very low harmonic and crossover distortion . distortion Furthermore , the device incorporates an original ( and patented ) short - circuit protection system comprising an arrangement for automatically limiting the dissipated power so as to keep the operating point of the output transistors within their safe operating range . A conventional thermal shutdown system is also included .
