HYBRID​ ​ON-OFF​ GRID​ SUNT-12.0KW-S-M​ IP65 รับประกันซ่อมฟรี 10 ปี

INVERTER ON/OFF GRID

Model : SUNT-12.0KW-S-M

PV Input

Start up Voltage : 150vdc

PV maximum input voltage : 500vdc

MPPT input range : 120~450Vdc

Maximum PV input power : 9600W + 9600W

PV Input Current : 30A+30A

Battery

Battery rated voltage : 48Vdc

DC input voltage range : 40-60Vdc

Maximum Charge current : 220A(Configurable)

Maximum Discharge current : 260A(Configurable)

AC Input

AC input rated voltage : 220/230/240Vac

AC input/Output rated frequency : 50/60Hz

Max input/Output Rated power : 12000W

Max. Bypass Current : 63A

Shift Time (Bypass and Inverter) : 10ms

AC Output

Max. Output power : 12000W

Peak Output Power : 24000W

Max. output current : 55A

Output voltage waveform : Pure sine wave

THD : 3%

Ingress Protection : IP65

Operating temperature range : -25~60°C

Net Weight : 39kg.
